Spur Gears
Our precision spur gears are available in many configurations and ensure reliable power transmission. These components are ideally suited for general mechanical engineering, precision mechanics, and the design of compact gearbox solutions. Available straight or helical, left-hand or right-hand, with a 20° pressure angle and various material options.
- Straight or helical toothing
- Left-hand or right-hand lead
- Pressure angle 20°
- Various material options
Response within 48h (Mon – Fri)
Volume discounts & freight cost coverage for annual orders on request.
Technical Overview
| Module | 0.3 – 8 |
| Number of Teeth | 10 – 150 |
| Temperature Range | -60°C to +120°C (material-dependent) |
| Gear Type | Straight / helical, left / right |
| Pressure Angle | 20° |
| Materials | Brass, plastic, steel, Lauramid |
These are basic values. Detailed technical information and diagrams can be found in the PDF catalogue.
